Optical Distribution Point Aerial Closure
Optical Distribution Point Aerial Closure CV021 is 2 I/P 2 O/P closure that used in aerial hanged in outdoor for fiber optic communication network building. This optical closure for optic fiber cable may be exposed to severe enviromental conditions. And it shall provide good durability and long term reliability in these conditions.
Description:
The closure CV021 consists of outer cases, gaskets, trays and inner kits. The closures have two main entry ports on each end. The outer cases consists of the left and right housing and constructed of highly chemical resistant material for long life using. Each splice cassette is able to accommodate 24 individual fiber fusion splices.
Features:
Same dome closure design in left and right side.
It is easy to open and close the closures by hoop.
High quality PP material, greater impact strength.
4 inlet parts in the tray, available to meet the requirements for FTTH network
Aerial, pole mounted, wall-mounted, duct installation.
Big storage space for fiber splice tray, rotary angel more than 90°, easy for installation & maintenance.
Specification:
| Model | Dimension | Material | Splice tray | Max. capacity | Cable port | Structure |
| CV021 | Ф177x500mm | PP | 4 PCS | 96 FO | 4 port | Mechanical sealing |
Protection grounding device:
Insulation resistance: ≥2×104MΩ/500V(DC)
Withstanding Voltage: ≥15000V(DC)/1min, no breakdown, no flash over.
Main mechanical performance parameters
Extrude: Withstand ＞600N Axial tension
Squash: Withstand pressure 1500N/100mm
Shock: Withstand 16N·m, 3 times
Bending: The closure and connection between closure cover & base can withstand
bending tension 150N, bending angel ±45°, 10 cycles.
Accessories:
Fiber optic heat protect shrinkable sleeve
Cable tie
Insulating tape
Aerial hanged accessories
YHT mould and injection moulding workshop for producing Optical Distribution Point Aerial Closure.
